TD210 Industrial Cellular 4G LTE Modem SMS Controller with Terminal IO Block
TD210 Industrial Cellular 4G LTE Modem SMS Controller with Terminal IO Block Supports RS-232/485/422 I/O (suits all AU 4G Freq)
Freq. Bands: B1-B2-B3-B5-B7-B8-B20-B28 (Telstra and all other AU providers)
It has a built-in independent MCU chipset and multi-layer software detection and hardware protection mechanism to ensure reliability and stability.
TD210 supports transparent data transmission, helping you seamlessly transfer the data under MQTT, Modbus RTU, TCP/UDP protocol to your remote server.
TD210 supports up to 5 sync data centre, which enables you to receive the same data in a different location and backup your data.
A powerful and visual config tool, easy and convenient for you to configure, setup and diagnose the modems.
- Industrial MCU built in, rugged and reliable
- Global 4G/3G/2G compatible
- 1-RS232, 1-RS485
- Modbus RTU, MQTT, TCP/UDP
- AT Command, SMS, CSD
- Up to 5 sync data center
- Wide operation voltage: 5-35VDC
- Working temperature: -35°C~+75°C
Key Features
1. 1x RS232, 1x RS485 (Or RS422), 5x I/O.
2. Transparent data transfer, with built-in standard TCP/IP stack.
3. Multi data centres (up to 5) and TCP server, able to access center with the domain name and IP address.
4. TCP heartbeat link detection, keep device always online.
5. APN/VPDN
6. SMS backup, data will be transferred by SMS when TCP/UDP disconnects.
7. Rich online and offline trigger modes: SMB, Ring, Data (Sent through serial port). MQTT, Transparent (TCP Client/Server, UDP Client/Server), Modbus Gateway (Modbus RTU to Modbus TCP), SMS Alarm, DNS
Config Tool, SMS, Cloud DMP (Device Management Platform)
8. Hardware and software auto inspection technology, enable operation fault auto repairing.
9. OPEN WRT, support multiple developments
Specifications
