7seg click is an accessory board in mikroBUS form factor. It’s a compact and easy solution for adding a 2-digit seven-segment display to your device. It features two 74HC595 8-bit serial-in, parallel-out shift register modules as well as two seven-segment digits. 7seg Click communicates with target board via SPI interface. It has a LED diode (GREEN) that indicates the presence of power supply. SMD jumper is available for selecting whether the board will be operating on 3.3V or 5V power supply.

Downloads

 7Seg Click User Manual
 7Seg Click Examples



Specifications

Type LED Segment
Applications Board is ideal for adding popular 7 segment display to your device while using only 4 microcontroller pins
On-board modules Two 74HC595 8-bit serial-in, parallel-out shift register modules and two seven-segment digits
Key Features 100 MHz (typical) shift out frequency
Key Benefits Compact display solution with simple serial interface
Interface SPI,PWM,GPIO
Input Voltage 3.3V or 5V
Compatibility mikroBUS
Click board size M (42.9 x 25.4 mm)
