iMod X500 M3 MAX - Industrial Embedded Computer with iMod Software
iMod X500 is a modern, ready-to-use platform for automation systems designed by TECHBASE.
TECHBASE provides solutions for industrial automation, telemetry, remote access and integration with IT systems.
What is iMod X500?
It combines Industrial computer NPE X500 with iMod Software that provides:
- a ready-to-use product for automation systems and telemetry
- easy to configure functionalities, which provide trouble-free operation of your system
- a flexible platform you may use for carrying out any project
Proper selection of hardware resources and ready to use software packages enable you to adjust the functionalities of the device according to the requirements of your installation.
The iMod platform combines ease of use characteristic of simple devices with possibilities of an embedded computer.
Due to the constant development of applications and the possibility of remote update, you can update software and constantly increase the scope of functions of your device.
iModCloud - a cloud service - allows you to visualize and control parameters of any number of devices via a web browser.
With iModCloud, you can control all your facilities via any mobile device, register data and share selected information with other users.
The iMod platform guarantees a quick start and full use of the NPE computer, without the need to write complicated software. It is a fully configurable system, that represents the typical C-L-V usage. Due to the available SDK, the platform can be extended with newly dedicated functionalities.
iMod X500 can perform the following functions:
Data Logger:
iMod X500 telemetry module offers you huge opportunities for registering and data access, using built-in input/output interfaces and communication channels.
Protocol and Interface Converter:
Due to the flexible configuration, the device can operate as a protocol and interface converter:
- Modbus TCP
- Modbus RTU
- M-bus
- SNMP
- 1-Wire
In addition, due to the possibilities of the Linux operating system, each user can create their own protocols with the use of the available SDK.
Embedded Computer:
The design of the iMod X500 allows for trouble-free operation in industrial conditions. It has a fanless case and is characterised by high resistance to external conditions and high reliability. The Linux system provides stable operation of the device.
Telemetry Module:
iMod X500 is a multichannel telemetry module, providing constant uninterrupted access to data. It enables you to save the results of measurements and parameter values of connected devices - data can be saved to internal memory or to an SD/MMC card. You can also save data to internal and external databases.
PLC:
iMod X500 can operate as a typical PLC. The telemetry module can be programmed in ladder logic, which is easy to configure and allows for a quick start of an installation.
Industrial modem and GPRS, 3G or 4G/LTE router:
With a built-in GSM modem, iMod X500 offers advanced functions and can be configured as an industrial modem and a router operating in GPRS, EDGE network as well as in 3G or 4G/LTE mobile network. You can easily get a backup connection mode and define routing.
You can build a VPN with iMod X500. You can access other devices with one telemetry module with a defined public IP. The VPN guarantees the high security of data transmission.
I/O Expansion Module:
Due to digital I/O and analogue inputs, iMod X500 can successfully replace expansion modules.
