IQPH Industrial pH Sensor Modbus RS485 5m Cable

Description



IQPH Industrial pH Sensor Modbus RS485 5m Cable

The IQPH water pH sensor can be used for environmental water quality monitoring, acid/alkali/salt solutions, chemical reaction processes, and industrial production processes, and can meet the requirements for online pH measurement in most industrial applications.

Technical Specifications:

model
IQPH
Measuring range
0~14.00pH
resolution
0.01pH
Accuracy
±0.1pH,±0.3
Operating temperature
0~65
work pressure
0.2MPa
Temperature compensation
Automatic temperature compensation (NTC)
powered by
12~24VDC
Signal output
RS-485(Modbus/RTU)
shell material
POM
Installation method
Submersible installation, 3/4" NPT pipe thread
Cable length
5 meters, other lengths can be customized
Calibration method
Two point calibration
Power consumption
0.2W@12V
Protection level
IP68



Documents:

IQPH-D pH Sensor Datasheet

IQPH-D pH Sensor User Guide



IQPH Industrial pH Sensor Modbus RS485 5m Cable

Product form
Free pickup in our shop(s)

SKU: IQPH-D

$399.00 $349.00 Excl. GST

$349.00
Product available in stock.

    • We ship from our stock in AU (Perth), pickup by prior booking
    • We Offer Quantity Discounts for Large Orders 10+ qty (Request Quote)
    • We accept Purchase Orders & Net 30-day Payment for Eligible Accounts

    Description



    IQPH Industrial pH Sensor Modbus RS485 5m Cable

    The IQPH water pH sensor can be used for environmental water quality monitoring, acid/alkali/salt solutions, chemical reaction processes, and industrial production processes, and can meet the requirements for online pH measurement in most industrial applications.

    Technical Specifications:

    model
    IQPH
    Measuring range
    0~14.00pH
    resolution
    0.01pH
    Accuracy
    ±0.1pH,±0.3
    Operating temperature
    0~65
    work pressure
    0.2MPa
    Temperature compensation
    Automatic temperature compensation (NTC)
    powered by
    12~24VDC
    Signal output
    RS-485(Modbus/RTU)
    shell material
    POM
    Installation method
    Submersible installation, 3/4" NPT pipe thread
    Cable length
    5 meters, other lengths can be customized
    Calibration method
    Two point calibration
    Power consumption
    0.2W@12V
    Protection level
    IP68



    Documents:

    IQPH-D pH Sensor Datasheet

    IQPH-D pH Sensor User Guide
