mikromedia HMI Breakout Board

Description

mikromedia HMI Breakout Board

The mikromedia HMI breakout board is a simple accessory that conveniently enables developers to access pins from any of the 18 mikromedia HMI smart display boards. Each mikromedia HMI is powered by an FT900Q 32-bit MCU, and this board directly interfaces to it, which simplifies development in the prototyping phase (mikromedia HMI boards are intended for use as OEM parts). The breakout board also contains a micro USB port, an RJ-45 ethernet connector, as well as an external programmer connector (ideally used with mikroProg for FT90x). Two 24-pin flat cables are included in the packaging, enabling the use of both mikromedia HMI connectors at the same time (MAIN, CAMERA).

Downloads



Specifications

Type Adapter
Applications Breakout board for mikromedia HMI, to simplify the development process.
Programming mikroProg for FT90x connector
Interface GPIO
Input Voltage 5V (via USB)
Compatibility mikromedia



Tutorial Link

mikromedia HMI Breakout Board

Product form
Free pickup in our shop(s)

SKU: MIKROE-2300

$30.00 $15.00 Excl. GST

$15.00
Product available in stock.

    • We ship from our stock in AU (Perth), pickup by prior booking
    • We Offer Quantity Discounts for Large Orders 10+ qty (Request Quote)
    • We accept Purchase Orders & Net 30-day Payment for Eligible Accounts

    Description

    mikromedia HMI Breakout Board

    The mikromedia HMI breakout board is a simple accessory that conveniently enables developers to access pins from any of the 18 mikromedia HMI smart display boards. Each mikromedia HMI is powered by an FT900Q 32-bit MCU, and this board directly interfaces to it, which simplifies development in the prototyping phase (mikromedia HMI boards are intended for use as OEM parts). The breakout board also contains a micro USB port, an RJ-45 ethernet connector, as well as an external programmer connector (ideally used with mikroProg for FT90x). Two 24-pin flat cables are included in the packaging, enabling the use of both mikromedia HMI connectors at the same time (MAIN, CAMERA).

    Downloads



    Specifications

    Type Adapter
    Applications Breakout board for mikromedia HMI, to simplify the development process.
    Programming mikroProg for FT90x connector
    Interface GPIO
    Input Voltage 5V (via USB)
    Compatibility mikromedia



    Tutorial Link
