| Wireless Transmission |
| Protocol |
LoRaWAN® |
| Frequency |
CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power |
16 dBm (868 MHz)/20 dBm (915 MHz)/19 dBm (470 MHz) |
| Sensitivity |
-137 dBm @300bps |
| Mode |
OTAA/ABP Class A |
| Measurement |
| GNSS Positioning |
| Position Accuracy (CEP) |
5.0m (Direct Line of Sight) |
| Resolution |
Longitude/Latitude: 0.0001
Altitude: 1m |
| Time To First Fix |
Cold Start: 37s Average
Hot Start: 1s Average |
| Sensitivity |
Tracking: -167dBm
Reacquisition: -160 dBm
Cold Start: -148dBm
Hot Start: -159 dBm |
| Wi-Fi Positioning |
| Wi-Fi Positioning |
Indoor asset location using Wi-Fi access point scanning (device does not connect to Wi-Fi) |
| Wi-Fi Parameters |
BSSID, RSSI |
| Wi-Fi Standard |
802.11b/g/n 2.4GHz |
| Device Motion |
| Status |
Normal/Tilt |
| Temperature |
| Range |
-40 ~ 125°C |
| Resolution |
0.1°C |
| Operation |
| Power On & Off |
NFC, Power Button (Internal) |
| Configuration |
NFC, Bluetooth® 5.3 |
| Physical Characteristics |
| Power Supply |
4 × 2700 mAh ER14505 Li-SOCl2 Replaceable Batteries |
| Battery Life* |
Twice Daily Location Updates - 15+ Years |
| (25°C) |
Tenth Daily Location Updates - 8+ Years
Hourly location updates – 4+ Years |
| Operating Temperature |
-30°C ~ +70°C |
| Relative Humidity |
0 ~ 95% (Non-condensing) |
| Material & Color |
PC, Black |
| Ingress Protection |
IP67 |
| Impact Protection |
IK09 |
| Dimension |
110 × 70 × 30 mm (4.33 × 2.76 × 1.18 in) |
| Weight |
202g (Batteries are Included) |
| Installation |
Wall Screw Mounting, 3M Tape Mounting, Cable-tie Mounting |
