Description
Milesight EM500 CO2 Sensor (4 in 1)
EM500-CO2 is designed for measuring gaseous carbon dioxide (CO2) concentration in harsh environments. It is useful in the application where knowing CO2 level is important as a greenhouse, building ventilation, fruit and vegetable storage. Besides, it also supports temperature, humidity and barometric pressure measurement.
- 4 in 1 (CO2, barometric pressure, humidity, temperature)
- Measuring ranges from 400ppm to 5000ppm
- Easy installation in any enclosed areas or outdoors
- 19000 mAh Li-SOCL2 battery
- NFC enabled
- IP67 rated
- Easy Installation
Specifications
|
| LoRaWAN |
Frequency |
AU915/AS923 |
| Tx Power |
16dBm(868)/20dBm(915)/19dBm(470) |
| Sensitivity |
-147dBm @300bps |
| Mode |
OTAA/ABP Class A |
| Measurement (CO2)
|
Range |
400 – 5000 ppm |
| Resolution |
1 ppm |
| Accuracy |
±30 ppm or ±3 % of reading |
| Physical Characteristics |
Power Supply |
19000 mAh Li-SOCl2
|
| Operating Temperature |
30°C to +70°C |
| Ingress Protection |
IP66 |
| Dimension |
156.1 × 71 × 69.5 mm |
| Mounting |
DIN rail, wall, pole mounting |
Documentations:
EM500-CO2 Datasheet
