| Hardware System |
CPU |
Qualcomm Quad-core ARM Cortex-A7，716.8 MHz |
| Memory |
512 MB DDR3 RAM and 8 GB Flash |
| Cellular Interface |
Network |
5G/4G LTE |
| Antenna |
8 × Internal Antennas |
| SIM Slot |
1（Mini SIM-2FF） |
| Ethernet Interface |
Numbers |
2 × 10/100/1000 Mbps |
| Property |
1 × WAN + 1 × LAN or 2 × LAN |
| Mode |
Full or half duplex (Auto-Sensing) |
| PoE |
1 × 802.3af PoE PD on WAN/LAN Port |
| Wi-Fi Interface |
Antenna |
4 × Internal Antennas |
| Standards |
IEEE 802.11b/g/n，2.4 GHz
IEEE 802.11a/n/ac，5 GHz |
| Tx Power |
2.4 GHz: 26dBm (max)
5 GHz: 26.4dBm (max)
|
| Rx Sensitivity |
2.4G:
802.11b: ≤ -92dBm@11Mbps
802.11g: ≤ -78dBm@54Mbps
802.11ac VHT20: ≤ -91dBm@MCS0
802.11ac VHT20: ≤ -66dBm@MCS8
802.11ac VHT40: ≤ -88.5dBm@MCS0
802.11ac VHT40: ≤ -64dBm@MCS8
5G:
802.11a: ≤ -91dBm@6Mbps
802.11a: ≤ -76dBm@54Mbps
802.11ac VHT20: ≤ -90dBm@MCS0
802.11ac VHT20: ≤ -68dBm@MCS8
802.11ac VHT40: ≤ -87dBm@MCS0
802.11ac VHT40: ≤ -65dBm@MCS9
802.11ac VHT80: ≤ -84dBm@MCS0
802.11ac VHT80: ≤ -60dBm@MCS9 |
| Modes |
AP and Client mode |
| Security |
WPA/WPA2 authentication, WEP/TKIP/AES encryption |
| GPS 1(Optional) |
Antenna |
1 × Internal Antenna |
| Technology |
GPS/GLONASS/Beidou/Galileo/QZSS |
| Serial Interface |
Numbers |
1 × RS232 or 1 × RS485 (Switchable) |
| Connector |
3.5 mm Terminal Block |
| Baud Rate |
300bps to 230400bps |
| DI/DO |
Numbers |
1 × DI (dry contact) + 1 × DO (wet contact)， galvanic isolation |
| Connector |
3.5 mm Terminal Block |
| Maximum V/A |
0.3A@30VDC (DO) |
| Others |
Reset Button |
1 × RESET |
| LED Indicators |
1 × STATUS，1 × 5G (Cellular Networks) |
| Built-in |
Watchdog, RTC, Timer |
| Software |
Network Protocols |
PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS,
VRRP, HTTP, HTTPS, DNS, ARP, QOS, SNTP, Telnet, VLAN, SSH, etc. |
| VPN |
DMVPN, IPsec, OpenVPN, PPTP, L2TP, GRE |
| Security |
Access Control, DMZ, Port Mapping, MAC Binding, SPI Firewalls,
DoS&DDoS Protection, Filtering(IP&Domain), IP Passthrough |
| Management |
Web, CLI, SMS, On-demand dial up, SNMP v1/v2c/v3, DeviceHub |
| AAA |
Radius, Tacacs+, LDAP, Local Authentication |
| Multilevel Authority |
Multiple Levels of User Authority |
| Reliability |
VRRP, WAN Failover |
| Serial Port |
Transparent (TCP Client/Server, UDP), Modbus Master/Slave,
Modbus Gateway (Modbus RTU to Modbus TCP) |
| Power Supply |
Power Input² |
1. 9-48 VDC, with Surge-Protection and Reverse Polarity Protection
2. 802.3 af PoE PD |
| Power Connector |
2-pin 3.5 mm Terminal Block |
| Physical Characteristics |
Ingress Protection |
IP67 |
| Housing |
Polycarbonate + Metal |
| Dimension |
No Waterproof Connector: ф105 x 110 x 188 mm (ф4.13 x 4.33 x 7.40 in)
With Waterproof Connector: ф105 x 110 x 218 mm (ф4.13 x 4.33 x 8.58 in) |
| Installation |
Desktop, Pole Mounting, Wall Mounting, Bottom Magnetic/Lock Mounting |
| Environmental |
Operating Temperature |
-40°C to +70°C (-40℉ to +158℉) Reduced Cellular Performance Above 60°C |
| Storage Temperature |
-40°C to +85°C (-40℉ to +185℉) |
| Ethernet Isolation |
1.5 kV RMS |
| Relative Humidity |
0% to 95% (non-condensing) at 25°C/77℉ |
