| Wireless Transmission |
| Technology |
LoRaWAN® |
| Antenna |
Internal Antenna |
| Frequency |
IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power |
16dBm (868MHz)/22 dBm (915 MHz) |
| Sensitivity |
-137dBm |
| Mode |
OTAA/ABP Class A/Class C |
| Thermostat Feature |
| Compatibility |
Work with most HVAC systems via LoRaWAN®
Work with PTAC (2H/1C), Boilers, Furnaces or Heat Pumps (2H/1C) via Milesight UC7111 HVAC controllers
Work with radiators via Milesight WT101/WT102 thermostat |
| Temperature Control Mode2
|
Heat, EM (Emergency) Heat, Cool, Auto |
| Fan Mode2
|
Low, Medium, High, Auto, On, Circulate |
| Advanced Feature |
Local Control Schedule |
| Sensor |
| Temperature |
| Operating Principle |
Digital CMOSens® technology (MEMS) |
| Range |
-20°C ~ 60°C |
| Accuracy |
Typical ± 0.2°C, Maximum ± 0.5°C |
| Resolution |
0.1°C |
| Humidity |
| Operating Principle |
Digital CMOSens® technology (MEMS) |
| Range |
0% - 100% RH |
| Accuracy |
Typical ± 2% RH, Maximum ± 5% RH |
| Resolution |
0.5% RH |
| PIR |
| Detection Area |
120 ° Horizontal, 90 ° Vertical |
| Detection Distance |
Maximum 6 m |
| Others |
| Display |
2.7-inch Black&White E-ink Screen |
| Buttons |
5 Buttons for Power On/Off, Reset, System On/Off, Temperature Up/Down, Temperature Control Mode, Fan Mode, etc. |
| LED Indicator |
1 x Power/Reset Indicator |
| USB |
1 × Type-C for Power Supply or Console |
| Power Connector |
1 × 2-pin Power Terminal Connector (PowerBus) |
| Software |
| Power On/Off |
Button, Mobile App via NFC |
| Configuration |
Mobile App via NFC or Bluetooth® 5.0, Downlink |
| Advanced Feature |
Occupied Detection, Smart Display, Child Lock, Button Customization, External Sensor Mode, Multicast, FUOTA |
| Physical Characteristics |
| Power Supply3
|
1. 2 × 2700 mAh ER14505 Li-SOCl2 Replaceable Batteries
2. AC/DC 24V by Power Connector
3. DC 5V by Type-C Port
4. Powerbus (DC 24V) by Milesight HAVC Controller |
| Battery Life4
|
Class A: |
| (10 min report interval) |
5.2 years (SF7, EU868), 3.3 years (SF10, EU868)
4.8 years (SF7, US915), 2.7 years (SF10, US915)
Class C: Around 25 days |
| Operating Temperature |
-20°C ~ 60°C (E-ink Screen: 0°C ~ 40°C) |
| Relative Humidity |
0% to 95% (non-condensing) |
| Ingress Protection |
IP30 |
| Material & Color |
PC + ABS (UL94 V0), White |
| Dimension |
86 × 86 × 24 mm |
| Installation |
Wall Screw Mounting, 86mm Square or European 60mm Round Box Mounting, 118 or 120 Wall Box Mounting via Wall Plate Accessories |
