Power Adapter Kit 350W DC 24V 14.6A for reBot Arm B601-DM

Description

Power Adapter Kit 350W DC 24V 14.6A for reBot Arm B601-DM

This is a 350W high-efficiency industrial-grade AC-DC switching power supply delivering a stable DC 24V, 14.6A output. It features a selectable input voltage switch for 115VAC or 230VAC (compatible with a wide range of 90–264VAC) and achieves a typical efficiency of up to 88%.

Designed for robust performance, it includes comprehensive protection circuits against Short Circuit, Overload, Over Voltage, and Over Temperature. The integrated cooling fan features intelligent on/off control based on thermal load.

Fully compliant with international safety standards including IEC/UL 62368-1 and CCC (GB4943.1), this unit is ideal for industrial automation, control systems, and electronic instrumentation. It boasts exceptional reliability with an MTBF ≥ 2,099,900 hours.

Features:

  • High Efficiency Design — Typical efficiency up to 88% (24V model) with no-load power consumption <0.75W.
  • Wide Range Input — Selectable input voltage (90–132VAC / 180–264VAC) via switch; withstands 300VAC surge for up to 5 seconds.
  • Comprehensive Protections — Short Circuit, Overload (110–140% Hiccup mode, auto-recovery), Over Voltage (28.8–33.6V), and Over Temperature Protection.
  • Smart Cooling System — Built-in intelligent temperature-controlled fan; activates at ≥50°C and stops at ≤40°C to extend lifespan.
  • Extreme Environment Ready — Operates reliably from -25°C to +70°C (full load) and up to 5000m altitude.
  • Low Noise Output — Ripple & Noise ≤ 150mVp-p (measured at 20MHz bandwidth).
  • Global Safety Certified — Complies with IEC/UL 62368-1, CCC (GB4943.1), BSMI, and EAC TP TC 004 standards.
  • Superior Reliability — MTBF ≥ 2,099,900 hours (calculated per Telcordia SR-332).
  • Anti-Vibration Design — Withstands 5G vibration (10–500Hz) for 60 minutes in each axis (X, Y, Z).

Specification

Item Specification
Model Number Power Adapter Kit for reBot Arm B601-DM
Dimensions (L×W×H) 263.5 × 121 × 38.8mm（L×W×H）
Net Weight Approx. 0.76 kg
Input Voltage Range 90–132VAC / 180–264VAC (Selectable via Switch)
Frequency Range 47 – 63 Hz
AC Input Current 3.4A Max. @ 230VAC (Typical)
Inrush Current 60A @ 230VAC (Cold Start, Typical)
Efficiency (Typ.) 88%
DC Output Voltage DC 24V
Rated Output Current 14.6A
Rated Output Power 350.4W
Ripple & Noise ≤ 150mVp-p
Protections OLP / OVP / OTP / SCP
Operating Temp. -25°C ~ +70°C
Operating Humidity 20% ~ 90% RH (Non-condensing)
Storage Temperature -40°C ~ +85°C
Storage Humidity 10% ~ 95% RH
Safety Certificates IEC/UL 62368-1, CCC (GB4943.1), BSMI CNS15598-1, EAC TP TC 004, EN 61558-1, EN 61558-2-16, BIS IS13252(Part1), KC 62368-1 (for 12V/24V Models)



Read more

Power Adapter Kit 350W DC 24V 14.6A for reBot Arm B601-DM

Product form
Free pickup in our shop(s)

SKU: 100029903

$179.00 $149.00 Excl. GST

$179.00 $149.00
New stock coming, dispatch within 5-10 days.

    • Local AU Stock, Fast Same-Day Dispatch or Pickup
    • Price Match & Quantity Discounts Available (Request Quote)
    • Purchase Orders & Net 30-Day Terms for Approved Accounts
    • Free Local Technical Support Before & After Purchase
    • Custom Industrial IoT Solutions & Project Assistance
    • Trusted by Australian Industry, Utilities, Agriculture & Government

    Description

    Power Adapter Kit 350W DC 24V 14.6A for reBot Arm B601-DM

    This is a 350W high-efficiency industrial-grade AC-DC switching power supply delivering a stable DC 24V, 14.6A output. It features a selectable input voltage switch for 115VAC or 230VAC (compatible with a wide range of 90–264VAC) and achieves a typical efficiency of up to 88%.

    Designed for robust performance, it includes comprehensive protection circuits against Short Circuit, Overload, Over Voltage, and Over Temperature. The integrated cooling fan features intelligent on/off control based on thermal load.

    Fully compliant with international safety standards including IEC/UL 62368-1 and CCC (GB4943.1), this unit is ideal for industrial automation, control systems, and electronic instrumentation. It boasts exceptional reliability with an MTBF ≥ 2,099,900 hours.

    Features:

    • High Efficiency Design — Typical efficiency up to 88% (24V model) with no-load power consumption <0.75W.
    • Wide Range Input — Selectable input voltage (90–132VAC / 180–264VAC) via switch; withstands 300VAC surge for up to 5 seconds.
    • Comprehensive Protections — Short Circuit, Overload (110–140% Hiccup mode, auto-recovery), Over Voltage (28.8–33.6V), and Over Temperature Protection.
    • Smart Cooling System — Built-in intelligent temperature-controlled fan; activates at ≥50°C and stops at ≤40°C to extend lifespan.
    • Extreme Environment Ready — Operates reliably from -25°C to +70°C (full load) and up to 5000m altitude.
    • Low Noise Output — Ripple & Noise ≤ 150mVp-p (measured at 20MHz bandwidth).
    • Global Safety Certified — Complies with IEC/UL 62368-1, CCC (GB4943.1), BSMI, and EAC TP TC 004 standards.
    • Superior Reliability — MTBF ≥ 2,099,900 hours (calculated per Telcordia SR-332).
    • Anti-Vibration Design — Withstands 5G vibration (10–500Hz) for 60 minutes in each axis (X, Y, Z).

    Specification

    Item Specification
    Model Number Power Adapter Kit for reBot Arm B601-DM
    Dimensions (L×W×H) 263.5 × 121 × 38.8mm（L×W×H）
    Net Weight Approx. 0.76 kg
    Input Voltage Range 90–132VAC / 180–264VAC (Selectable via Switch)
    Frequency Range 47 – 63 Hz
    AC Input Current 3.4A Max. @ 230VAC (Typical)
    Inrush Current 60A @ 230VAC (Cold Start, Typical)
    Efficiency (Typ.) 88%
    DC Output Voltage DC 24V
    Rated Output Current 14.6A
    Rated Output Power 350.4W
    Ripple & Noise ≤ 150mVp-p
    Protections OLP / OVP / OTP / SCP
    Operating Temp. -25°C ~ +70°C
    Operating Humidity 20% ~ 90% RH (Non-condensing)
    Storage Temperature -40°C ~ +85°C
    Storage Humidity 10% ~ 95% RH
    Safety Certificates IEC/UL 62368-1, CCC (GB4943.1), BSMI CNS15598-1, EAC TP TC 004, EN 61558-1, EN 61558-2-16, BIS IS13252(Part1), KC 62368-1 (for 12V/24V Models)



    Read more
