R711 Netvox LoRaWAN Wireless Indoor Temperature Humidity Sensor
Netvox R711, mainly used to detect the indoor air temperature and humidity, collects the data and sends it to other devices for display through the wireless network communication module. The wireless communication meets standard LoRaWAN™ Protocol (Class A).
Frequency Range: AU915-928，AS923
Features:
- Compatible With LoRaWAN™ Protocol
- 2 X 1.5V AA Alkaline Battery
- Reports Battery Voltage, Indoor Air Temperature and Humidity
- Easy Set Up and Installation
Electric
|
Input Power
|
2 X 1.5V AA Batteries
|
|
Operating Power
|
DC 2.4V～3V
|
|
Standby Current
|
12uA/3V
|
|
Transmitting Current (Max)
|
120mA/3V
|
|
Receiving Current (Max)
|
11mA/3V
|
Physical
|
Dimension
|
L:112mm*W:34mm*H:17mm
|
|
Weight
|
83.8g
|
|
Operating Humidity
|
＜90%RH
|
|
Operating Temperature
|
-20°C - 55°C
|
|
Storage Temperature
|
-40°C － 85°C
|
|
Temperature Measurement Range
|
-20°C － 55°C
|
|
Temperature Measurement Accuracy
|
±0.5°C @25°C Max. +/-0.8°C@ -20°C~55°C
|
|
Humidity Measurement Range
|
10%RH － 0%RH
|
|
Humidity Measurement Accuracy
|
±4%RH @25°C
|
Documentation:
Datasheet
User manual
Netvox LoRaWAN Catalog
Payload Format and Examples
Netvox LoRaWAN Application Command V1.9
Netvox LoRaWAN Application Devicetype V1.9
Example of payload (ConfigureCmd)_R718CK2
example of payload (ReportDataCmd)
Frequency Conversion (Sub frequencies of AU915)
Lora Calibrate Tool User Manual
Programming Instruction STlink
