The WisGate Soho Lite is a compact, cost-effective Semtech SX1302/SX1303 gateway for LoRaWAN for small and medium indoor IoT deployments. It features Cat-1 LTE cellular connectivity, 12V DC input, and the option to select between a built-in or external LTE antenna, giving you full control over your installation preferences.
Designed for simplicity and reliability, the Soho Lite is ideal for expanding LoRaWAN coverage in smart buildings, small offices, and indoor sensor networks. It is powered by WisGateOS 2, ensuring quick setup, intuitive configuration, and seamless integration with WisDM for cloud-based device management.
Why You Need WisGate Soho Lite
The RAK7266 gateway helps extend your LoRaWAN coverage quickly and cost-effectively.
Why it’s useful:
-
Flexible Connectivity Options – Supports Cat-1 LTE, WiFi, and Ethernet for dependable IoT data transmission.
-
Fast and Simple Setup – WisGateOS 2 makes configuration straightforward, even for first-time LoRaWAN users.
-
Compact for Indoor Use – RAK7266 is a LoRaWAN gateway for smart offices, residential buildings, and other small-scale indoor environments.
Key Features of WisGate Soho Lite
- 8 uplink / 1 downlink LoRaWAN channels
- LoRa Concentrator: Semtech SX1302/SX1303
- Cellular: LTE Cat-1
- WiFi: 2.4 GHz 802.11b/g/n
- Ethernet Port: 1x 10/100 Mbps RJ45 (no PoE)
- Flexible LTE antenna options (built-in or external)
- Power input: 12V DC Adapter (included)
- Fully integrated with WisDM for remote management
Key Benefits of WisGate Soho Lite
This gateway offers reliable LoRaWAN performance for indoor environments where stable and efficient coverage are essential.
-
LoRaWAN channel support: 8 uplink and 1 downlink channels for steady, multi-sensor communication.
-
Standard power support: Operates on 12V DC input (adapter included) for straightforward power integration.
Use Case #1: Extending Coverage in Buildings
In older buildings with thick walls and no wired infrastructure, reliable wireless coverage can be tough to achieve. The WisGate Soho Lite provides seamless indoor LoRaWAN connectivity using LTE, making deployment fast and hassle-free.
Use Case #2: Facility Monitoring with Cloud Management
Small facility managers often need to monitor temperature, air quality, and water leaks across different rooms. Its compact form factor and cloud management allow sensor placement anywhere with centralised monitoring.
Comparison Table: WisGate Edge Lite 2, WisGate Soho Pro, and WisGate Soho Lite
WisGate Edge Lite 2 and Soho Lite are compact, indoor-friendly gateways with PoE and LTE, while Soho Pro is rugged, supports broader power input and outdoor IP67 use. Only Edge Lite 2 supports Ethernet and PoE together. Here's the table breakdown for deeper comparison.
|
WisGate Soho Lite (RAK7266)
|
WisGate Edge Lite 2 (RAK7268V2/CV2)
|
WisGate Soho Pro (RAK7267)
|
|
LoRa Channels
|
8
|
8
|
8
|
|
LoRa Chipset
|
SX1302/SX1303*
|
SX1302
|
SX1303
|
|
Backhaul Options
|
Ethernet, WiFi, LTE
|
Ethernet, WiFi, LTE
|
WiFi, LTE
|
|
Cellular Module
|
Cat-1 LTE
|
Cat-4 LTE
|
Cat-1 LTE
|
|
WiFi Support
|
2.4 GHz (AP + Client)
|
2.4 GHz (AP + Client)
|
2.4 GHz (AP + Client)
|
|
Ethernet
|
1x 10/100 Mbps
|
1x 10/100 Mbps
|
No
|
|
PoE Support
|
No
|
Yes (802.3af/at)
|
No
|
|
Power Supply
|
12V DC
|
12V DC(9~24V DC*) or PoE
|
9~36V DC or Battery Plus
|
|
Enclosure & IP Rating
|
Plastic, IP30 (Indoor)
|
Plastic, IP30 (Indoor)
|
UV stabilised ABS, IP67 (Indoor/outdoor)
|
|
Dimensions (mm)
|
166 x 127.5 x 36
|
166 x 127.5 x 36
|
180 x 130 x 60
|
|
Weight
|
0.3 kg
|
0.3 kg
|
0.66 kg
|
|
Operating Temp
|
-10 to 55 °C
|
-10 to 55 °C
|
-30 to 55 °C
|
|
Operating Humidity
|
0~95% RH
|
0~95% RH
|
0~95% RH
|
|
LoRaWAN Bands
|
EU868/IN865/RU864/US915/AU915/KR920/AS923-1/2/3/4/EU433/CN470*
|
|
Firmware
|
WisGateOS 2
|
WisGateOS 2
|
WisGateOS 2
|
|
Management Platform
|
WisDM
|
WisDM
|
WisDM
|
|
LoRaWAN Features
|
UDP Packet Forwarder, Basics Station Forwarder, MQTT Bridge, Built-In NS, LBT*
|
|
Multi-WAN/Failover
|
Yes
|
Yes
|
Yes
|
|
* Features related to the model selection/sub-model
|
|
Applicable Use Cases
|
Compact indoor projects with LTE fallback
Cost-effective small-scale IoT
Smart panels, testbeds, pilot networks, coverage optimisation
|
Indoor deployments with Ethernet + PoE
SME IoT use cases needing Cat-4 LTE
Smart buildings, offices, and industry
|
Harsh indoor/outdoor conditions (IP67)
Solar-powered or mobile setups (Battery Plus)
Farms, remote sites, agriculture, smart city
|
What’s in the Box
- 1 pc RAK7266 Gateway
- 1 pc LoRa Antenna
- 1 pc Power Supply
- 1 pc Mounting Bracket
- 1 pc Screw Kit for Mounting
- 1 pc LTE Antenna (only included with external LTE antenna variant)
How to Get Started with WisGate Soho Lite
Frequently Asked Questions
Why should I choose the WisGate Soho Lite?
-
Simplicity & Affordability: This compact LoRaWAN gateway offers core LoRaWAN features at a cost-effective pricing, ideal for small projects or new deployments.
-
Technical Flexibility: It uses the Semtech SX1302/SX1303 LoRa chipset for efficient radio performance, and the LTE Cat-1 module supports reliable cellular backhaul.
-
Antenna Options: Choose between a built-in or external LTE antenna based on your indoor coverage and signal strength needs.
-
Multiple Access Types: With WiFi and Ethernet, you have backup options if LTE isn’t stable.
-
Remote Fleet Management: Fully compatible with WisDM, RAKwireless’ cloud platform for managing multiple gateways from anywhere.
How do I set up the WisGate Soho Lite?
- Power the gateway using the included 12V DC adapter. If cellular is used, insert the SIM card before powering the gateway.
- Connect to the gateway's WiFi AP to access the WisGateOS 2 web interface.
- Configure your preferred connectivity method and set up the LoRaWAN part.
- Add the gateway to WisDM for remote management if desired.
How do I manage the gateway remotely?
-
Create an account at https://wisdm.rakwireless.com/.
- Register your gateway using its EUI and Serial Number.
- From the WisDM dashboard, you can view status, update firmware, reboot, or change settings remotely.
