Seeed Studio Grove - Line Finder v1.1

Description

Seeed Studio Grove - Line Finder v1.1

Most of the automated robotic projects start from a line-following robot, Grove - Line finder v1.1 is designed to achieve this task easily and quickly. Those eye-like sensors on the board are actually IR emitting LED and sensitive phototransistor. When the phototransistor detects the reflected infrared light from the IR emitting LED, it will output a digital signal, which changes from HIGH to LOW.

Features

  • Easy to use

  • Integrated indicator LED

  • Digital output

  • Adjustable detecting range.

Specifications

  • Power supply: 5V DC

  • Digital output mode: TTL (High when black is detected, Low when white is detected)

  • Connector: 4 pin Buckled Grove interface

  • Dimension: 20mm*20mm

  • Comparator: LMV358

  • Photo-reflective diode: RS-06WD

Technical Details

Dimensions 24.2mm x 20mm x 10.8mm
Weight G.W 10g    N.W 8.3g
Battery Exclude
Power supply 5V DC
Digital output mode TTL (High when black is detected, Low when white is detected)
Connector 4 pin Buckled Grove interface
Comparator MV358
Photo-reflective diode RS-06WD

Documents



Seeed Studio Grove - Line Finder v1.1

Product form
Free pickup in our shop(s)

SKU: 101020172

$10.00 $5.00 Excl. GST

$5.00
Product available in stock.

    • We ship from our stock in AU (Perth), pickup by prior booking
    • We Offer Quantity Discounts for Large Orders 10+ qty (Request Quote)
    • We accept Purchase Orders & Net 30-day Payment for Eligible Accounts
