SN50v3 Waterproof Long Range Wireless LoRaWAN Sensor Node
SN50v3 Waterproof Long Range Wireless LoRaWAN Sensor Node
SN50V3-LB/LS LoRaWAN Sensor Node is a Long Range LoRa Sensor Node. It is designed for outdoor use and powered by 8500mAh Li/SOCl2 battery or solar powered + li-on battery for long term use.SN50V3-LB/LS is designed to facilitate developers to quickly deploy industrial level LoRa and IoT solutions. It help users to turn the idea into a practical application and make the Internet of Things a reality. It is easy to program, create and connect your things everywhere.
SN50V3-LB/LS wireless part is based on SX1262 allows the user to send data and reach extremely long ranges at low data rates.It provides ultra-long range spread spectrum communication and high interference immunity whilst minimizing current consumption.It targets professional wireless sensor network applications such as irrigation systems, smart metering, smart cities, and so on.
SN50V3-LB/LS has a powerful 48Mhz ARM microcontroller with 256KB flash and 64KB RAM. It has multiplex I/O pins to connect to different sensors.
SN50V3-LB/LS has a built-in BLE module, user can configure the sensor remotely via Mobile Phone. It also supports OTA upgrades via private LoRa protocol for easy maintenance.
SN50V3-LB/LS is the 3rd generation of the LSN50 series generic sensor node from Dragino. It is an open-source project and has a mature LoRaWAN stack and application software. User can use the pre-load software for their IoT projects or easily customize the software for different requirements.
Features:
- LoRaWAN 1.0.3 Class A
- SX1262 LoRa Core
- Ultra-low power consumption
- Open-source hardware/software
- Bands: CN470/EU433/KR920/US915/EU868/AS923/AU915/IN865
- Support Bluetooth v5.1 and LoRaWAN remote configure
- Support wireless OTA update firmware
- Uplink on periodically
- Downlink to change configure
- 8500mAh Li/SOCl2 battery (SN50v3-LB)
- Solar panel + 3000mAh Li-on battery (SN50v3-LS)
- IP65 Water Proof
- External LoRa Antenna
Applications:
- Wireless Alarm and Security Systems
- Home and Building Automation
- Automated Meter Reading
- Industrial Monitoring and Control
- Long-range Irrigation Systems,etc.
Specifications:
Common DC Characteristics:
- Supply Voltage: Built-in battery , 2.5v ~ 3.6v
- Operating Temperature: -40 ~ 85°C
I/O Interface:
- Battery output (2.6v ~ 3.6v depends on battery)
- +5v controllable output
- 3 x Interrupt or Digital IN/OUT pins
- 3 x one-wire interfaces
- 1 x UART Interface
- 1 x I2C Interface
LoRa Spec:
- Frequency Range, Band 1 (HF): 862 ~ 1020 Mhz
- Max +22 dBm constant RF output vs.
- RX sensitivity: down to -139 dBm.
- Excellent blocking immunity
Battery:
- Li/SOCI2 un-chargeable battery
- Capacity: 8500mAh
- Self-Discharge: <1% / Year @ 25°C
- Max continuous current: 130mA
- Max boost current: 2A, 1 second
Power Consumption:
- Sleep Mode: 5uA @ 3.3v
- LoRa Transmit Mode: 125mA @ 20dBm, 82mA @ 14dBm
Documents:
- Firmwre, Documents Directory
- User Manual -- Online Latest
- Shared Folder for all Dragino Products
- Source Code: Hardware, Software
