Teltonika FTC924 Next-gen 4G LTE Cat 1 vehicle GPS Tracker Bluetooth 5.4
Teltonika FTC924 Next-Generation 4G LTE Cat 1 Vehicle GPS Tracker with Enhanced GNSS Accuracy
The Teltonika FTC924 is a next-generation 4G LTE Cat 1 GPS tracker designed for reliable fleet tracking, insurance telematics, anti-theft protection and vehicle monitoring. Built on Teltonika's latest Fleet Telematics (FT) platform, the FTC924 delivers improved GNSS accuracy, Bluetooth® 5.4 connectivity and optimised power management, making it an excellent choice for modern commercial vehicles and fleet operators.
Supporting multiple satellite constellations, intelligent sleep modes and Bluetooth Low Energy (BLE) sensors, the FTC924 enables real-time vehicle tracking, driver behaviour monitoring and cold chain applications while helping minimise vehicle battery consumption.
When integrated with IQFLOW Cloud, the FTC924 provides live GPS tracking, geofencing, fleet analytics, historical route playback, event notifications and remote device management.
Key Features
- 4G LTE Cat 1 with automatic 2G GSM fallback
- Bluetooth® 5.4 Low Energy
- Enhanced multi-GNSS positioning
- Internal high-gain GNSS and LTE antennas
- Built on Teltonika FT (Fleet Telematics) Platform
- 2 Digital Inputs
- 1 Analog Input
- 1 Digital Output
- Digital Ground Sense input
- 170 mAh internal backup battery
- USB Type-C configuration
- 128 MB internal flash memory
- Accelerometer for movement detection
- FOTA Web remote firmware updates
Enhanced GNSS Accuracy
The FTC924 delivers more accurate positioning than previous-generation devices by supporting multiple satellite systems and tracking up to 41 visible satellites, improving location quality in challenging environments.
Supported GNSS constellations include:
- GPS
- GLONASS
- Galileo
- BeiDou
Performance includes:
- Position accuracy: <1.8 m CEP
- Tracking sensitivity: -165 dBm
- 75-channel GNSS receiver
- Hot start: <1 second
- Warm start: <25 seconds
This enhanced positioning improves fleet visibility, route optimisation and location-based services.
Bluetooth® 5.4 Sensor Connectivity
Integrated Bluetooth® 5.4 Low Energy expands the FTC924 beyond traditional vehicle tracking by supporting wireless sensors and beacons.
Compatible Bluetooth peripherals include:
- Teltonika EYE Beacons
- Temperature sensors
- Humidity sensors
- Asset tags
- Magnet detection sensors
- Movement sensors
Ideal applications include:
- Cold chain monitoring
- Driver identification
- Cargo monitoring
- Asset management
- Warehouse logistics
Intelligent Fleet Monitoring
The FTC924 incorporates an internal accelerometer and intelligent event detection to improve fleet safety and operational efficiency.
Supported features include:
- Trip detection
- Overspeed alerts
- Network jamming detection
- Device unplug detection
- Ignition detection
- Driver behaviour monitoring
These functions help reduce unauthorised vehicle use, improve driving habits and support insurance telematics applications.
Optimised Power Management
Designed for long-term vehicle installations, the FTC924 features intelligent sleep modes that significantly reduce vehicle battery consumption when the vehicle is parked.
Available sleep modes include:
- Online Sleep
- Deep Sleep
- Power-Off Sleep
A built-in 170 mAh Li-Ion backup battery allows the tracker to continue operating temporarily during external power interruptions, enhancing security and event reporting.
Flexible Vehicle Integration
The FTC924 provides essential vehicle I/O interfaces for fleet monitoring and automation.
Available interfaces include:
- 2 Digital Inputs
- 1 Analog Input
- 1 Digital Output
- Digital Ground Sense
- USB Type-C
- Nano-SIM
These interfaces support integration with:
- Ignition sensing
- Door sensors
- Alarm buttons
- Fuel level sensors
- Buzzers
- Immobiliser relays
- LED indicators
Easy Configuration & Remote Management
The FTC924 is quick to deploy and easy to manage using Teltonika's software ecosystem.
Configuration options include:
- Teltonika Configuration Tool (TCT)
- USB Type-C connection
- SMS configuration
- FOTA Web firmware updates
Integrated with IQFLOW Cloud, the FTC924 enables:
- Live vehicle tracking
- Geofence alerts
- Driver behaviour reporting
- Fleet dashboards
- Historical trip reports
- Remote diagnostics
- Device health monitoring
Technical Specifications
| Feature |
Specification |
| Cellular |
4G LTE Cat 1 with GSM fallback |
| GNSS |
GPS, GLONASS, Galileo, BeiDou |
| Position Accuracy |
<1.8 m CEP |
| GNSS Receiver |
75 channels |
| Bluetooth |
Bluetooth® 5.4 LE |
| Backup Battery |
170 mAh Li-Ion |
| Input Voltage |
10–30 V DC |
| Digital Inputs |
2 |
| Analog Inputs |
1 |
| Digital Output |
1 |
| Digital Ground Sense |
Yes |
| Memory |
128 MB Flash |
| SIM |
Nano-SIM |
| USB |
USB Type-C |
| Dimensions |
93 × 43 × 12.5 mm |
| Weight |
65 g |
| Operating Temperature |
-40°C to +85°C (without battery) |
Specifications sourced from the official Teltonika FTC924 Datasheet.
Typical Applications
- Fleet Management
- Insurance Telematics
- Commercial Vehicle Tracking
- Driver Behaviour Monitoring
- Cold Chain Logistics
- Delivery Fleets
- Rental Vehicles
- Company Cars
- Asset Tracking
- Anti-Theft Protection
- Service Vehicles
- Utility Fleets
