Teltonika Mesh Anchor Fixed Reference Point for Indoor Positioning Wirepas Mesh
Teltonika Mesh Anchor Wirepas® Fixed Reference Point for Accurate Indoor Positioning
The Teltonika Mesh Anchor is a dedicated Wirepas Mesh reference node designed to provide accurate indoor positioning and reliable communications across enterprise-scale asset tracking networks. Acting as a permanent fixed reference point, the Mesh Anchor enhances location accuracy while maintaining continuous, self-healing communication between Wirepas Mesh gateways, anchors and tags.
Unlike conventional indoor positioning systems that require extensive wired infrastructure, the Mesh Anchor is battery powered, requires no SIM card or mobile subscription, and can be deployed quickly throughout warehouses, hospitals, manufacturing plants and logistics facilities. Together with Teltonika EYE Beacon Mesh and EYE Sensor Mesh devices, it creates a highly scalable indoor tracking ecosystem capable of supporting thousands of connected assets.
When integrated with IQFLOW Cloud, the Mesh Anchor enables room-level asset visibility, intelligent inventory management, environmental monitoring and real-time location services across large industrial environments.
Key Features
- Wirepas Mesh v5.x reference anchor
- Fixed reference point for indoor positioning
- Self-healing wireless mesh networking
- Battery-powered operation
- No SIM card or mobile subscription required
- Supports thousands of connected devices
- Intelligent 3-in-1 network architecture
- BLE beaconing (iBeacon® & Eddystone)
- Replaceable AA batteries
- Mesh network firmware updates
- Industrial-grade design
- Easy wall mounting
Fixed Reference Points for Accurate Indoor Positioning
The Mesh Anchor provides permanent reference locations that improve the accuracy and stability of indoor positioning systems.
By installing multiple anchors throughout a facility, organisations can:
- Improve indoor location accuracy
- Track assets at room level
- Increase network reliability
- Enhance positioning consistency
- Expand mesh coverage
This makes the Mesh Anchor an essential infrastructure component for enterprise indoor tracking deployments.
Reliable Wirepas Mesh Communication
Built on Wirepas Mesh v5.x, the Mesh Anchor continuously participates in the network, ensuring reliable communication between gateways and mobile Mesh devices.
Key benefits include:
- Self-healing communication paths
- Automatic route optimisation
- Continuous data flow
- Reliable operation if devices move or disconnect
- Highly scalable network architecture
The decentralised mesh network automatically reroutes data when network conditions change, helping maintain uninterrupted communications.
No SIM Cards or Cabling Required
Unlike traditional wireless infrastructure, the Mesh Anchor operates without mobile connectivity or Ethernet cabling.
Benefits include:
- No SIM cards
- No mobile subscriptions
- Wireless deployment
- Lower operating costs
- Simplified installation
- Flexible placement
Battery-powered operation allows rapid deployment in locations where wired infrastructure is unavailable or impractical.
Intelligent 3-in-1 Mesh Network
The Mesh Anchor forms part of Teltonika's intelligent indoor positioning ecosystem.
The network connects:
- Mesh Gateways
- Mesh Anchors
- Mesh Tags (EYE Beacon Mesh & EYE Sensor Mesh)
Together, these devices exchange information across a single Wirepas Mesh network, providing seamless communication and accurate indoor asset tracking throughout the facility.
Long Battery Operation
The Mesh Anchor is powered by four replaceable AA alkaline batteries, enabling long-term autonomous operation.
Battery features include:
- 4 × AA (1.5 V) alkaline batteries
- Approximately 5,600 mAh total capacity
- Replaceable batteries
- Batteries supplied pre-installed
- Simple activation by removing insulating tabs
This battery-powered design eliminates the need for permanent power wiring and supports flexible deployment throughout large facilities.
Industrial Hardware Design
The Mesh Anchor is designed for reliable operation in commercial and industrial environments.
Features include:
- Durable ABS plastic enclosure
- IP40 protection
- UL94 V-0 flame-retardant housing
- Operating temperature: -20°C to +60°C
- Wall mounting with two M4 screws
- Optional plastic mounting bracket
Its compact enclosure is suitable for permanent installation throughout warehouses, production facilities and healthcare environments.
BLE Beacon Compatibility
In addition to Wirepas Mesh networking, the Mesh Anchor supports standard Bluetooth® beacon broadcasting.
Supported beacon protocols include:
This allows integration with a wide range of Bluetooth-enabled indoor positioning and IoT applications.
IQFLOW Cloud Integration
When deployed with compatible Teltonika Mesh Gateways and Mesh Tags, the Mesh Anchor integrates seamlessly with IQFLOW Cloud, enabling:
- Indoor asset positioning
- Warehouse inventory management
- Equipment tracking
- Medical asset monitoring
- Environmental monitoring
- Room-level location services
- Asset utilisation reporting
- Enterprise dashboards and alerts
IQFLOW Cloud provides a complete platform for managing large-scale indoor tracking deployments across multiple facilities.
Technical Specifications
| Feature |
Specification |
| Network Technology |
Wirepas Mesh v5.x |
| BLE Support |
iBeacon®, Eddystone |
| Frequency |
2.402–2.480 GHz |
| TX Power |
Up to +7 dBm EIRP |
| Antenna |
Integrated directional planar antenna |
| Processor |
Nordic nRF52832 SoC (ARM Cortex-M4) |
| Power Supply |
4 × AA alkaline batteries |
| Battery Capacity |
Approximately 5,600 mAh |
| Battery Type |
Replaceable |
| Protection Rating |
IP40 |
| Material |
ABS plastic |
| Dimensions |
124 × 100 × 28 mm (including flanges) |
| Weight |
197 g |
| Operating Temperature |
-20°C to +60°C |
| Mounting |
Wall mounting (2 × M4 screws) |
Specifications are based on the official Teltonika Mesh Anchor Datasheet.
Typical Applications
- Indoor Asset Tracking
- Warehouse Inventory Management
- Smart Manufacturing
- Medical Equipment Tracking
- Industrial IoT
- Logistics & Distribution Centres
- Tool & Equipment Monitoring
- Smart Warehouses
- Factory Asset Tracking
- Enterprise Indoor Positioning
- Condition Monitoring Infrastructure
- Wirepas Mesh Network Expansion
