Teltonika PR3P2AU3 AU Power Supply 24W 4-pin connector 12V 2A
Genuine Australian 24W Power Supply for Teltonika Industrial Routers, Gateways and Network Devices
The Teltonika PR3P2AU3 AU Power Supply 24W is an official Teltonika power adapter engineered to provide reliable and stable power for compatible Teltonika industrial routers, gateways, switches, and networking devices. Featuring an Australian Type I mains plug, 12V DC output, 2A current rating, and a 4-pin industrial connector, the PR3P2AU3 is ideal for powering higher-performance Teltonika networking equipment used in industrial automation, IoT, SCADA, security, and telecommunications applications.
Designed for continuous operation, the PR3P2AU3 incorporates universal AC input, DoE Level VI energy efficiency, integrated short-circuit protection, and 4000V isolation to ensure safe and dependable operation in demanding industrial environments.
Key Features
Genuine Teltonika Power Supply
Designed specifically for compatible Teltonika networking products, including:
- Industrial Cellular Routers
- Industrial IoT Gateways
- Ethernet Switches
- Cellular Modems
- Remote Monitoring Devices
- Industrial Edge Controllers
The factory-fitted 4-pin connector provides quick, secure, and reliable installation.
Australian Type I Plug
The PR3P2AU3 features:
- Australian Type I AC Plug
- Direct Wall Plug Design
- Suitable for Australian and New Zealand power outlets
No additional plug adapters are required for local installations.
Why Choose the PR3P2AU3?
The PR3P2AU3 is the ideal replacement or spare power supply for Teltonika devices requiring a higher current capacity.
Key advantages include:
- Genuine Teltonika Accessory
- Australian Type I Plug
- Regulated 12V DC Output
- 2A Output Current
- 24W Maximum Output Power
- Industrial 4-Pin Connector
- 2 Metre Cable Length
- Built-in Short Circuit Protection
- 4000V Isolation Protection
- DoE Level VI Energy Efficiency
Electrical Specifications
AC Input
| Specification |
Value |
| Input Voltage |
100–240 VAC |
| Input Frequency |
50/60 Hz |
| Input Current |
0.8 A |
| Input Connector |
Australian Type I Plug |
The universal AC input range supports reliable operation across a wide variety of mains power systems.
DC Output
| Specification |
Value |
| Output Voltage |
12 VDC |
| Output Current |
2.0 A |
| Maximum Output Power |
24 W |
| Output Connector |
4-Pin Connector (3 mm Pitch) |
Provides stable regulated power for compatible Teltonika industrial networking devices.
Industrial 4-Pin Connector
The PR3P2AU3 uses Teltonika's standard industrial connector.
Connector Specifications
- 4-Pin Connector
- 3 mm Pin Pitch
- Pre-Moulded Connector
- Secure Connection Design
Compatible with many Teltonika industrial networking products using the 4-pin DC power interface.
Protection Features
The PR3P2AU3 incorporates electrical protection to maximise equipment safety and reliability.
Protection Functions
- Short Circuit Protection
- Regulated Output Voltage
- High Voltage Isolation
HIPOT (Dielectric Withstand Test)
- Primary to Secondary Isolation: 4000 VDC
These features help protect connected equipment against electrical faults and power anomalies.
Input and Output Tolerances
Input Operating Range
| Specification |
Value |
| Absolute Input Voltage |
90–264 VAC |
| Frequency Range |
47–63 Hz |
| Inrush Current |
60 A |
Output Voltage Tolerance
Ensures consistent output voltage for stable operation of connected networking equipment.
Energy Efficiency
The PR3P2AU3 complies with:
Efficiency Standard
Benefits include:
- Reduced Standby Power Consumption
- Improved Energy Efficiency
- Lower Operating Costs
- Suitable for Continuous 24/7 Operation
Reliability
MTBF
Designed for dependable long-term performance in industrial and commercial environments.
Physical Specifications
Dimensions
| Dimension |
Size |
| Length |
69.3 mm |
| Width |
41.4 mm |
| Height |
27.6 mm |
Cable Length
Connector
- 4-Pin Connector
- 3 mm Pin Pitch
- Connector Length: 29.3 mm
Weight
The longer cable allows flexible installation inside equipment cabinets and industrial enclosures.
Compatible Applications
The PR3P2AU3 is suitable for powering compatible Teltonika devices requiring a 12V DC input and 4-pin power connector, including:
- Industrial Cellular Routers
- Industrial Gateways
- Ethernet Switches
- Industrial IoT Controllers
- SCADA Equipment
- Remote Monitoring Systems
- Telecommunications Equipment
- Industrial Automation Devices
Always verify voltage and connector compatibility before installation.
Certifications and Compliance
Safety Standards
- AS/NZS 60950.1:2015
- AS/NZS 60065:2012 (Including Amendment A1)
EMC Compliance
- AS/NZS CISPR 22:2009+A1:2010
- AS/NZS CISPR 13:2012
- EN 55032:2012
- EN 55024:2010
- EN 55020:2007+A11
- EN 61000-3-2:2014
- EN 61000-3-3:2013
Designed to meet Australian and international safety and electromagnetic compatibility requirements.
