Teltonika RUTM16 Industrial Rugged Cellular LTE 4G Cat 6 eSIM Router
Industrial LTE Cat 6 Router with Built-In eSIM, Wi-Fi 5, GNSS & Gigabit Ethernet
The Teltonika RUTM16 is a next-generation industrial 4G LTE Cat 6 router engineered for global IoT deployments, industrial automation, transportation, smart city infrastructure, utilities, and enterprise networking. Featuring built-in eSIM functionality, Dual-SIM redundancy, Gigabit Ethernet, dual-band Wi-Fi 5, GNSS positioning, and advanced RutOS networking, the RUTM16 delivers flexible, secure, and scalable connectivity for mission-critical applications.
According to the official Teltonika datasheet and flyer, the RUTM16 supports LTE Cat 6 speeds up to 300 Mbps, worldwide LTE coverage, up to 7 eSIM profiles, advanced VPN services, industrial protocols, and RMS remote management.
Key Features
-
Built-In eSIM with Remote Profile Management
Manage carrier profiles remotely with support for up to 7 eSIM profiles, reducing deployment and maintenance costs.
-
4G LTE Cat 6 with Carrier Aggregation
Delivers download speeds up to 300 Mbps for high-performance industrial networking.
-
Worldwide LTE Support
Telit Cat 6 modem ensures broad global compatibility across multiple regions and carriers.
-
Dual-SIM Failover + eSIM
Advanced failover logic with auto-switching based on signal quality, roaming, data limits, and connectivity status.
-
Dual-Band Wi-Fi 5 (802.11ac Wave 2)
Supports MU-MIMO, mesh networking, fast roaming, and up to 150 simultaneous users.
-
5 × Gigabit Ethernet Ports
Includes 1 × WAN and 4 × LAN Gigabit ports with support for up to 128 VLANs.
-
Integrated GNSS Tracking
GPS, GLONASS, Galileo, BeiDou, and QZSS support for fleet tracking and location services.
-
Industrial Protocol Support
Native support for MQTT, OPC UA, Modbus, DNP3, DLMS/COSEM, and MQTT Gateway functionality.
Why Choose the Teltonika RUTM16?
The RUTM16 is ideal for deployments requiring:
- Global LTE compatibility
- Remote carrier profile management via eSIM
- Reliable Dual-SIM failover
- Industrial-grade security and VPNs
- High-speed Gigabit networking
- Wireless mesh networking
- GNSS location tracking
- Remote industrial device management
Its combination of advanced LTE connectivity, eSIM scalability, and industrial networking features makes it ideal for large-scale IoT and industrial infrastructure projects.
Typical Applications
- Smart city infrastructure
- Industrial automation & SCADA
- Smart transportation systems
- EV charging infrastructure
- Smart energy & utility monitoring
- Retail & POS connectivity
- Fleet management & tracking
- Roadside and traffic systems
- Remote industrial IoT gateways
- Enterprise branch networking
Technical Highlights
Cellular Connectivity
- 4G LTE Cat 6
- Up to 300 Mbps download / 50 Mbps upload
- 3G fallback support
- 3GPP Release 12 modem
eSIM & SIM Features
- Built-in consumer-type eSIM
- Up to 7 eSIM profiles
- Dual Mini-SIM slots
- Automatic SIM switching
- Multiple PDN support
- Band management
- SIM idle protection
- Auto APN configuration
Wi-Fi
- Dual-Band Wi-Fi 5 (802.11ac Wave 2)
- MU-MIMO support
- Wireless mesh (802.11s)
- Fast roaming (802.11r)
- Up to 867 Mbps
- Supports up to 150 users
Ethernet
- 1 × Gigabit WAN port
- 4 × Gigabit LAN ports
- 10/100/1000 Mbps
- Up to 128 VLANs supported
GNSS & Location Services
Supports:
- GPS
- GLONASS
- Galileo
- BeiDou
- QZSS
- Geofencing
- NTRIP
- NMEA 0183 output
VPN & Security
Supports:
- OpenVPN
- IPsec
- WireGuard
- GRE
- PPTP/L2TP
- SSTP
- ZeroTier
- DMVPN
- Tailscale
- Tinc VPN
Industrial Protocols
- MQTT
- OPC UA
- Modbus TCP/USB
- DNP3
- DLMS/COSEM
- Modbus MQTT Gateway
Hardware Platform
- MediaTek Dual-Core 880 MHz CPU
- 256 MB DDR3 RAM
- 16 MB NOR Flash + 256 MB NAND Flash
USB & I/O
- USB 2.0 Host port
- 1 × Digital Input
- 1 × Digital Output
Power
- 9–50 VDC industrial input
- Passive PoE via LAN1
- Reverse polarity & surge protection
Physical Specifications
- Anodized aluminium housing
- Dimensions: 132 × 44.2 × 104 mm
- Weight: 530 g
Operating Environment
- Operating temperature: -40°C to +75°C
- IP30 rated
Resources:
Teltonika RUTM16 Flyer
Teltonika RUTM16 Datasheet
Teltonika RUTM16 Quick User Guide
Teltonika RUTM16 User Guide
Teltonika RUTM16 3D Models
