UC51X LoRaWAN Wireless Solenoid Valve Controller

Description



UC51X LoRaWAN Wireless Solenoid Valve Controller

  • Empower Automatic & Precision Irrigation
  • Solenoid Valve Control
  • Water Flow Monitoring
  • IP67 Waterproof
  • Long Battery Life

Solenoid Valve Control

2 x output for connecting DC latching solenoid valve

  • Time-Based Control
  • Volume-Based Control

Water Flow Monitoring

2 x digital input for connecting water meter

  • Programmable Unit per Pulse
  • Enable Precise Irrigation

IP67 Waterproof

Equipped with IP67 rated enclosure to satisfy the outdoors all-weather long time operation.

Flexible Installation

LoRaWAN Solenoid Valve Controller Installation




Specifications

Model UC511 UC512
Power Supply Rechargeable
4900 mAh battery with solar panel
1-month battery life without charging (Class C)
Non-rechargeable
Replaceable 19000 mAh Li-SOCI2 battery
Up to 3-year battery life (Class A)
Solenoid interface 2 ×2-Wire 12 VDC Latching Solenoid
Dimension 120.1 ×120.1 ×55.4 mm (4.73×4.73×2.18 in)
Frequency AU915/AS923
Ingress Protection lP67
operating Temperature -20~60°c

UC51X LoRaWAN Wireless Solenoid Valve Controller

Product form
Free pickup in our shop(s)

SKU: UC511-DI-915M

$299.00 $269.00 Excl. GST

$269.00
Product available in stock.

    • We ship from our stock in AU (Perth), pickup by prior booking
    • We Offer Quantity Discounts for Large Orders 10+ qty (Request Quote)
    • We accept Purchase Orders & Net 30-day Payment for Eligible Accounts

    Description



    UC51X LoRaWAN Wireless Solenoid Valve Controller

    • Empower Automatic & Precision Irrigation
    • Solenoid Valve Control
    • Water Flow Monitoring
    • IP67 Waterproof
    • Long Battery Life

    Solenoid Valve Control

    2 x output for connecting DC latching solenoid valve

    • Time-Based Control
    • Volume-Based Control

    Water Flow Monitoring

    2 x digital input for connecting water meter

    • Programmable Unit per Pulse
    • Enable Precise Irrigation

    IP67 Waterproof

    Equipped with IP67 rated enclosure to satisfy the outdoors all-weather long time operation.

    Flexible Installation

    LoRaWAN Solenoid Valve Controller Installation




    Specifications

    Model UC511 UC512
    Power Supply Rechargeable
    4900 mAh battery with solar panel
    1-month battery life without charging (Class C)
    Non-rechargeable
    Replaceable 19000 mAh Li-SOCI2 battery
    Up to 3-year battery life (Class A)
    Solenoid interface 2 ×2-Wire 12 VDC Latching Solenoid
    Dimension 120.1 ×120.1 ×55.4 mm (4.73×4.73×2.18 in)
    Frequency AU915/AS923
    Ingress Protection lP67
    operating Temperature -20~60°c
