Wio Tracker L1 Pro Meshtastic GPS Tracker

Description

Wio Tracker L1 Pro Meshtastic GPS Tracker

The Wio Tracker L1 Series is a low-power, scalable Meshtastic node featuring LoRa (862–930 MHz), an nRF52840 for efficient processing, and an L76K GPS for precise location tracking. The L1 Pro version is a fully integrated, ready-to-deploy solution featuring an OLED display, rechargeable battery, and durable 3D-printed enclosure. Built for field use with no assembly required.

  • Ready-to-Use 3D-Printed Enclosure

The L1 Pro comes with a rugged, lightweight 3D-printed enclosure designed for immediate use—no additional assembly needed. Whether handheld or clipped onto gear, it’s built for adventure in any environment.

  • Pre-flashed with Meshtastic firmware

Ready to use out of the box with pre-installed Meshtastic firmware for seamless setup.

  • Triple Power Supply Options

Equipped with a built-in 2000 mAh battery, Type-C fast charging, and solar input support, enabling flexible deployment in diverse environments—perfect for outdoor and mobile use.

  • High Expandability

Fully compatible with the Grove ecosystem, and includes PTH headers and an SWD debugging interface for custom hardware expansion and advanced development.


Specification

Processor

Nordic nRF52840ARM® Cortex®-M4 with FPU runs up to 64 MHz

On-chip Memory

1 MB flash and 256 kB RAM

Wireless

LoRa: Based on Wio-SX1262, supports 862-930MHz

Bluetooth 5.0

GPS

L76K(GPS,BeiDou,GLONASS,QZSS)

OLED Display

Size: 1.3 inch

Resolution: 128*64 pixels

Active Area(mm): L34.5*W23.0*H1.47

Power

Type-C: 5v---1A

Solar energy interface: 5v---1A

Battery interface: 3.7v---1A

Certification

FCC, CE, RoHS


Hardware Overview

  • Diagram

Application

Part List

Wio Tracker L1 Board with 1.3 inch OLED Display, 3D-Printed Enclosure and battery

x1

LoRa Antenna

x1





Wio Tracker L1 Pro Meshtastic GPS Tracker

Product form
Free pickup in our shop(s)

SKU: 114993649

$109.00 $89.00 Excl. GST

$89.00
New stock coming, dispatch in about 15 days.

    • We ship from our stock in AU (Perth), pickup by prior booking
    • We Offer Quantity Discounts for Large Orders 10+ qty (Request Quote)
    • We accept Purchase Orders & Net 30-day Payment for Eligible Accounts

    Description

    Wio Tracker L1 Pro Meshtastic GPS Tracker

    The Wio Tracker L1 Series is a low-power, scalable Meshtastic node featuring LoRa (862–930 MHz), an nRF52840 for efficient processing, and an L76K GPS for precise location tracking. The L1 Pro version is a fully integrated, ready-to-deploy solution featuring an OLED display, rechargeable battery, and durable 3D-printed enclosure. Built for field use with no assembly required.

    • Ready-to-Use 3D-Printed Enclosure

    The L1 Pro comes with a rugged, lightweight 3D-printed enclosure designed for immediate use—no additional assembly needed. Whether handheld or clipped onto gear, it’s built for adventure in any environment.

    • Pre-flashed with Meshtastic firmware

    Ready to use out of the box with pre-installed Meshtastic firmware for seamless setup.

    • Triple Power Supply Options

    Equipped with a built-in 2000 mAh battery, Type-C fast charging, and solar input support, enabling flexible deployment in diverse environments—perfect for outdoor and mobile use.

    • High Expandability

    Fully compatible with the Grove ecosystem, and includes PTH headers and an SWD debugging interface for custom hardware expansion and advanced development.


    Specification

    Processor

    Nordic nRF52840ARM® Cortex®-M4 with FPU runs up to 64 MHz

    On-chip Memory

    1 MB flash and 256 kB RAM

    Wireless

    LoRa: Based on Wio-SX1262, supports 862-930MHz

    Bluetooth 5.0

    GPS

    L76K(GPS,BeiDou,GLONASS,QZSS)

    OLED Display

    Size: 1.3 inch

    Resolution: 128*64 pixels

    Active Area(mm): L34.5*W23.0*H1.47

    Power

    Type-C: 5v---1A

    Solar energy interface: 5v---1A

    Battery interface: 3.7v---1A

    Certification

    FCC, CE, RoHS


    Hardware Overview

    • Diagram

    Application

    Part List

    Wio Tracker L1 Board with 1.3 inch OLED Display, 3D-Printed Enclosure and battery

    x1

    LoRa Antenna

    x1
